ChargePoint CP6000 - Civil and Mechanical Design; Component Dimensions and Weights

2 Civil and Mechanical Design
2
Use the guidance below to design the civil and mechanical aspects of the site.
Each charging station can be installed attached to a wall or on a concrete pedestal with a Cable
Management Kit (CMK). The pedestal can be a newly poured pad or an existing concrete surface.
Component Dimensions and Weights
Each CP6000 charging station can be mounted on a pedestal or on a wall with a Cable Management Kit
(CMK). The station is a vertical enclosure with the weights and dimensions shown below.
Station Configuration Approximate Weight
Single port, wall 62 kg (136 lb)
Dual port, wall 68 kg (150 lb)
Single port, pedestal 71 kg (155 lb)
Dual port, pedestal 76 kg (168 lb)
5
