ChargePoint CP6000 - Tools and Materials; Installation into New Concrete

Tools and Materials
In addition to the CP6000 Concrete Mounting Template kit, the site construction team needs:
l
Digging tools (shovel, spade, etc.)
l
Materials to prepare the form for pouring concrete
l
Concrete as specified by site drawings
l
Rebar as specified by site drawings
l
24 mm (1 in) wrench
l
Level
l
Cut-resistant gloves
l
Drill or hydraulic hole punch (if using armored cable)
l
Conduit, ducting, or armored cable in the amounts and types specified by site drawings, that
complies with local code (see the rest of this document for conduit sizes and routing)
Installation into New Concrete
WARNING: Failure to install the ChargePoint CP6000 in accordance with these instructions and
all local building practices, climate conditions, safety standards, and all applicable codes and
ordinances may lead to risk of death, injury, or property damage, and will void the Limited One-
Year Parts Exchange Warranty.
1. Trench and excavate an opening to accommodate the wiring conduit and the concrete mounting
pad that meets local codes and requirements, per site drawings.
2. Run conduit to each station as needed. If the station needs wired Ethernet access, run Ethernet
conduit.
3. Build the form and lay rebar for the foundation.
l
The concrete block must measure at least 600 mm (24 in) on all sides.
l
The conduit stub-up needs to measure between 152 mm (6 in) and 590 mm (23.2 in) above
the concrete surface
IMPORTANT: It is critical that the conduits are positioned properly and plumb. The
tolerance where the conduits enter the station is 2 mm (1/16 in).
4. Align the CP6000 CMT over the conduit stub-ups with the two bolts facing forward and the third
bolt to the rear.
