Install on Existing Concrete
IMPORTANT: Always check local codes to ensure compliance. You may need to adjust these
instructions to comply with codes that apply at your installation location.
Review the CP6000 Site Design Guide and ensure that the dimensions of the existing concrete slab meet
the requirements.
If you are installing a Cable Management Kit (CMK), make sure there is adequate clearance behind the
power stub-up for the CMK.
To safely mount a CP6000 charging station, the concrete must be at least 150 mm (6 in) thick. At this
thickness, all of the CP6000 mounting bolts must be positioned as follows:
o
At least 380 mm (15 in) from the front edge
o
At least 300 mm (12 in) from the side edges
o
At least 150 mm (6 in) from the rear edge of the concrete slab
IMPORTANT: If the existing pad does not meet the specifications above, a structural engineer
must inspect and approve the pad for CP6000 charging station dimensions and weight.
Replace an Existing Charging Station
If you are replacing a CPF50 charging station, contact ChargePoint to order a CPF50 Adapter Kit.
If an existing charging station (from a manufacturer other than ChargePoint) is already in place at the
installation site, complete these tasks:
o
Turn off all power to the station and disassemble according to the original manufacturer’s
instructions.
o
Cut away any existing bolts or non-power conduit stub-up to ground level.
o
You may need to plug cut-away conduits at the slab end and disconnect wiring at the other end.
IMPORTANT: If existing conduit stub-up diameter is greater than 32 mm (1-1/4 in), you must
remove the concrete and replace it.
34
