Do Not Connect to These Systems
l
208 V AC 3Ø Wye, ungrounded
Floating Neutral
Voltage of either line to ground is undetermined
Neutral is not grounded
l
120/240 V AC 3Ø Delta, corner-grounded
Voltage of any line is not 120 V nominal relative to ground
l
Any system where the center point of the AC power source is not grounded.
21
Grounding Requirements
