Overview and Utilities
Product Specifications
UltraDoser Body Dimensions:
Reservoir height: 18” (457mm)
Hexagonal: 6” (197mm)
Arm reach : 12” or 18” (305mm or 457mm) from stand
dependent on mounting bracket location
UltraDoser Dosing Head:
Standard Head: 2”W x 9.5”H (51mm x 241mm)
EP Head: 2”W x 11”H (51mm x 279mm)
Total Weight:
UltraDoser: 32 lbs (14.5kg)
2K Controller: 22.5 lbs (10.2kg)
Dosing Range:
0.002 – 14 grams/dose
Dosing Accuracy:
+/- 2% of dose weight
Timing Range:
5.5 - 1000 milliseconds in 0.1 millisecond intervals
Control Voltage:
24 VDC
Materials:
Stainless steel construction. Built to food and beverage
industry standards.
Crate Dimensions:
58”L x 58”W x 24”H (1473 x 1473 x 609mm)
300 lbs with stand (136 kg)
225 lbs without stand (102kg)
Utility Requirements
Electrical Supply:
100-240 VAC 50-60Hz 110 W
Liquid Nitrogen:
Portable Dura-Cyl dewar – 22 psi (1.5 bar)
Bulk Tank (House Fed) System (with Chart Phase Separator) -
– 100 psi (6.9 bar)
Maximum flow rate 15 gallons (56 liters) per hour
Gaseous Nitrogen:
60 to 100 psi (4.1 to 6.9 bar)
10 SCFH gas per 100 bottles (or containers) per minute
