CHART ULTRADOSER 2K - Common Replacement Parts

Common Replacement Parts
Item No.
Part Description
Part No.
ULTRADOSER PARTS
1
UltraDoser Body
15170
2
Head Assembly
2.1
EP Head Assembly (Optional)
1005
2.1.1
Dosing Stem (Valve) Assembly
670.38
2.1.2
Solenoid Valve Spare Assembly
2450.16
2.2
Head Assembly (Standard)
2.2.1
Dosing Stem (Valve) Assembly
141
2.2.2
Solenoid Valve Spare Assembly
535
3
Dosing Head Heater (no cable included)
106C
4
Vent Heater Assembly (no cable included)
105C
5
Distribution Block
571
6
Vent Heater Cable – 4mt (D-1)
105C.01
7
Nozzle (Dosing Head) Heater Cable – 1.2mt (D-2)
1411
8
Timing / Container Sensor Cable Assembly – 2mt (D-3)
2440.16
9
Dose Solenoid Cable – 1.5mt (D-4 for Std Head)
2045
10
Dose Solenoid Cable – 1.5mt (D-4 for EP Head)
323
11
Confirm Sensor Cable – 1.5mt (D-5 for Std Head)
1201
12
Confirm Sensor Cable – 1.5mt (D-5 for EP Head)
323
13
75 Micron, 1/8” M x F Snubber
160
14
SRV, 50 psi
211
15
Distribution Block Cable – 5mt
577
SENSORS
16
Complete Sensor Bracket Assembly (install at UltraDoser head)
1422
17
12mm Inductive Proximity Sensor (Speed & Timing Sensor)
2807
18
Encoder (3/8” shaft)
2870.08
19
Encoder Cable – 20ft
2870.22
NOT SHOWN
18mm Photoelectric Sensor (default Bottle Detect Sensor)
2870.10
NOT SHOWN
18mm Sensor Support Hardware (use with PN 1422)
694
2K CONTROLLER PARTS
20
Controller Assembly – 2KS (Siemens)
2880
20
Controller Assembly – 2KA (Allen Bradley)
2870
21
Controller Mounting Assembly
2384
22
Controller Power Cord Assembly – 4mt
410
MISC PARTS
23
Doser Stand
119
24
Stand Base
326A
NOT SHOWN
C-Flex Fill Hose – 10ft
123
NOT SHOWN
Y-Pattern Manual Globe Valve
S6OMYCD
NOT SHOWN
Y-Pattern Purge Kit
C6454
