Warning Level Alarms – These warning alarms are provided to assist in troubleshooting any lack of
functionality. These warning alarms trigger a solid yellow light.
WARN #1 – Started Dosing with no shutdown faults. (green) –
[gives a green starting reference on the alarm history screen.]
WARN #2 - Dosing is Disabled. – [Dosing has been manually
disabled from the HMI.]
WARN #3 - Continuous Dosing CPM threshold exceeded. – [The
actual CPM exceeds the ‘continuous dosing’ setpoint.
WARN #4 - Liquid Level too low. – [Check the Liquid Level
sensor or calibration.]
WARN #5 - Liquid Level too high. – [Check the Liquid Level
sensor or calibration.]
WARN #6 - Inlet Pressure too low. – [Check the Inlet Pressure
sensor or calibration.]
WARN #7 - Inlet Pressure too high. – [Check the Inlet Pressure
sensor or calibration.]
WARN #8 - Dose Delay too long. – [Dose delay was longer than
the timing sensor interval. Check the Dose Delay setpoint.]
Level 2 Alarms – These sensor alarms require checking sensors if persistent. These alarms trigger a solid
red light.
FAULT #20 - Speed Sensor Pulses not seen on input #0. –
[Check the wiring to input #0, 24VDC power, or the Speed
Sensor.]
FAULT #21 - Speed Sensor Pulses not seen on input #4. –
[Check the wiring to input #4, 24VDC power, or the Speed
Sensor.]
FAULT #22 – Timing Sensor Pulses not seen on input #1. –
[Check the wiring to input #1, 24VDC power, or the Pocket
Sensor.]
FAULT #23 – Container Sensor not seen on input #12. – [Check
the wiring to input #12, 24VDC power, or the Bottle Present
Sensor.]
FAULT #24 - Valve Confirm Sensor Pulses not seen on input #3.
– [Check the wiring to input #3, 24VDC power, or the Valve
Confirm Sensor.]
FAULT #25 - Liquid Level very low. – [Check the Liquid Level
sensor or calibration.]
FAULT #26 - Inlet Pressure very high. – [Check the Inlet
Pressure sensor or calibration.]
Level 3 Alarms – These alarms are severe internal control wiring problems. These alarms trigger a solid
red light.
FAULT #32 – Internal PLC error. PWM Pulses not seen on input
#2. – [Check the wiring to input #2 or 24VDC power.]
