USER INTERFACE
EN
|
Intelect
®
Mobile 2 ELECTROTHERAPY User Manual
DEVICE USER INTERFACE
SCREEN DESCRIPTION
. Menu Bar
. Main Area
. Channel Bar
Each screen contains the following areas:
Menu Bar
Located at the top of each screen and lists the current screen name.
Go to Home Screem Go to Previous Screen Current Screen Name
Battery level
USB (Black connected, Grey inacctive)
Settings
