CAC Gasoline Engine Maintenance And Servicing Manual
100
27.without connection line
28.speed sensor positive input
29.λsensor positive input
30.throttle valve potentiometer signal input
31.intake air temperature sensor signal input
32.absolute pressure sensor signal input
33.without connection line
34.main ground wire of engine
35.ignition switch +12V power supply input
A/C I/O may only be supplied to the vehicle equipped with A/C and the ECU of the corresponding engine,
i.e. the vehicle of single-point injection with A/T.
