DC Wiring Color Codes (Continued)
Wire # Function Color
200 FWD AUTO BILGE BROWN/RED
201 FWD MANUAL BILGE BROWN
205 AFT AUTO BILGE BROWN/RED
206 AFT MANUAL BILGE BROWN
210 HIGH WATER BILGE BROWN/RED
211 HIGH WATER ALARM RED
270 MACERATOR BROWN/VIOLET
272 FISH BOX PUMP BROWN/VIOLET
280 WATER PUMP BROWN/BLUE
282 RAW WATER PUMP BROWN/BLK
295 TRIM TABS ORANGE
296 PORT TRIM TAB RED
297 STBD TRIM TAB GREEN
300 VHF ORANGE
301 CHART PLOTTER RED
303 DIGITAL SOUNDER VIOLET
305 HORN ORANGE
325 TANK COMMON GRAY
326 WATER TANK WHITE/BLUE
327 HOLDING TANK WHITE/GREEN
328 HEAD COMMON GREEN
340 HEAD RED
372 STEREO MEMORY RED/YELLOW
374 STEREO POWER RED
384 FWD PORT SPKR+ WHITE/RED
385 FWD PORT SPKR- WHITE/YELLOW
Table 3.4. DC Wiring Color Codes
3-23 3-23
