DC Wiring Color Codes (Continued)
Wire # Function Color
385 FWD PORT SPKR- WHITE/YELLOW
386 FWD STBD SPKR + WHITE/GREEN
387 FWD STBD SPKR- WHITE/BLK
388 AFT PORT SPKR + WHITE/RED
389 AFT PORT SPKR - WHITE/YELLOW
390 AFT STBD SPKR + WHITE/GREEN
391 AFT STBD SPKR - WHITE/BLK
425 HEAD LT BLUE
450 NAVIGATION LT GRAY
455 ANCHOR LT GRAY
460 BACKLT BLUE
470 BILGE LT BLUE/YELLOW
475 COCKPIT LT BLUE/RED
476 WHITE T-TOP LT BLUE/WHITE
477 RED T-TOP LT BLUE/RED
478 SPREADER LT BLUE/YELLOW
490 BAITWELL LT BLUE/GREEN
520 FUEL SENDER PINK
550 REFRIGERATOR RED/BLK
611 RAW WATER BONDING GREEN
650 FUEL TANK BONDING GREEN
651 FUEL FILL BONDING GREEN
660 WASTE C-COCK BONDING GREEN
815 BATTERY CHARGER WHITE
Table 3.5. DC Wiring Color Codes
3-24 3-24
Systems
