2.1.2 Touch-it XELO Front Panel / Front Panel glass
The variant Touch-it XELO Front Panel is designed for front mounting.
Each Front Panel has its own cut-out drawing.
For the appropriated drawing see the specific data sheet.
To clamp the Front Panel into the cut-out you can use the attached fasting clamps (Vari-
ant Front Panel) or the mounted fasting clamps (Front Panel glass).
CAUTION!
For the best installation result the use of all provided fasting
clamps is highly recommended. Depending on individual installa-
tion circumstances a new IP rating may be considered.
