Christ touch-it xelo - Extension Connector (Additional Interfaces)

Touch-it XELO
Operating Instructions
Copyright / © Christ Electronic Systems GmbH 15 / 47 March 2017, Revision 17
a member of the Christ Company Group Document No.: E461201
2.5 Extension Connector (additional Interfaces)
Extension Connector
1 x Emergency Stop
8 x Individual Selectable Buttons / Switches / LEDs
EtherCAT
1 x EtherCAT® Slave (Buttons / Switches / LEDs)
Additional connector side Touch-it XELO Automation
