Touch-it XELO
Operating Instructions
Copyright / © Christ Electronic Systems GmbH 14 / 47 March 2017, Revision 17
a member of the Christ Company Group Document No.: E461201
2.4 Interfaces Connector Side (CPU i5-6300U)
USB
4 x USB Host 3.0 (Type A)
1 x USB Host 3.1 (Type C)
Ethernet
2 x 1 Gbit Ethernet (Intel I219LM + I211AT)
Communication
1 x RS-232 / RS422 / RS-485 (BIOS setting) (RJ50 10P10C)
Video
1 x DisplayPort
WLAN
1 x 802.11 ac/a/b/g/n 2.4 GHz, 5 GHz, (optional)
Power Connector
Phoenix
Connector side Touch-it XELO (CPU i5-6300U)
Connector side Optional (CPU i6-4300U )
On/Off is only included with housing VESA and VESA glass.
All interfaces are described in the chapter Interfaces.
