Touch-it XELO
Operating Instructions
Copyright / © Christ Electronic Systems GmbH 17 / 47 March 2017, Revision 17
a member of the Christ Company Group Document No.: E461201
3.1.1 Changing Display Resolution
3.1.1.1 CPU T56N
In the BIOS Setup mode choose the Chipset Menu select North Bridge and then
Graphics Configuration.
Set the LVDS2 Panel Type
Save this configuration by pressing “F4” and selecting “Yes” afterwards.
3.1.1.2 CPU GX-415GA
To change the display resolution the following settings must be done.
In the BIOS Setup mode choose the Chipset Menu select LVDS Panel Config Select.
Set the LVDS Panel Config Select.
Save this configuration by pressing “F4” and selecting “Yes” afterwards.
3.1.1.3 CPU i5-4300U
To change the display resolution the following settings must be done.
In the BIOS Setup mode choose the Chipset Menu select
System Agent (SA) Configuration -> Graphics Configuration -> LCD Control.
Set the LCD Panel Type.
Save this configuration by pressing “F4” and selecting “Yes” afterwards.
3.1.1.4 CPU i5-6300U
To change the display resolution the following settings must be done.
In the BIOS Setup mode choose the Advanced Menu select
LVDS(eDP/DP) Configuration.
Set the LCD Panel Type.
Save this configuration by pressing “F4” and selecting “Yes” afterwards.
