Touch-it XELO
Operating Instructions
Copyright / © Christ Electronic Systems GmbH 19 / 47 March 2017, Revision 17
a member of the Christ Company Group Document No.: E461201
3.1.3 Changing COM Port
3.1.3.1 CPU GX-415GA
To change the COM Port to RS-422 / RS-485 / RS-232 the following settings must be done.
In the BIOS Setup mode choose the Advanced Menu select F81866 Super IO Configuration.
Select Serial Port0 Configuration and be sure that Serial Port [Enabled] is set.
Set the Mode Select to your favourite interface.
Save this configuration by pressing “F4” and selecting “Yes” afterwards.
3.1.3.2 CPU i5-4300U
To change the COM Port to RS-422 / RS-485 / RS-232 the following settings must be done.
In the BIOS Setup mode choose the Advanced Menu select NCT6102D Super IO Configura-
tion.
Select Serial Port0 Configuration and be sure that Serial Port [Enabled] is set.
Set the Mode Select to your favourite interface.
Save this configuration by pressing “F4” and selecting “Yes” afterwards.
3.1.3.3 CPU i5-6300U
To change the COM Port to RS-422 / RS-485 / RS-232 the following settings must be done.
In the BIOS Setup mode choose the Advanced Menu select Fintek Super IO Configuration
and then Serial Port1 Configuration.
Set the Device Mode to your favourite interface.
Save this configuration by pressing “F4” and selecting “Yes” afterwards.
