Electrical Safety Analyzer 19032-P Quick Start Guide
41
RAMP TIME: The needed time which rises to setting voltage. It inputs 0 to
indicate it is OFF.
FALL TIME: The needed time which falls from setting voltage value to
zero, 0 means OFF.
RANGE: It sets the test file of insulation resistance, AUTO means auto
range. The relationship between current range and resistance
measurement scope are shown as below table.
IR Value
Range
Setting Voltage
50V ~ 499V
Setting Voltage
500V ~ 1000V
10mA(3~10mA)
0.1MΩ~1MΩ 0.1MΩ~4.5MΩ
3mA(0.3~3mA) 0.5MΩ~4.5MΩ 3.0MΩ~15.0MΩ
300uA(30~300uA)
3.0MΩ~15.0MΩ
10.0MΩ~45MΩ
30uA(3~30uA)
10.0MΩ~45MΩ 35.0MΩ~450MΩ
3uA(0.3~3uA)
45MΩ~0.45GΩ
0.40GΩ~4.5GΩ
300nA(20~300nA)
0.40GΩ~4.9GΩ 4.0GΩ~50.0GΩ
Note
Please follow test voltage and insulation impedance of DUT to
calculate the value of current thus follow this to choose suitable
current range.
CHNL (H-L): The setting is the same as AC/DC CHANNEL.
Or scanning test selection point (please use with optional
device, for example 6000-03).
Leakage current test mode (LC) ---- Option
Pause test mode (PA)
MESSAGE: Message hint string. The string are inputted by alphabet,
Arabic numerals or symbol [ - ]. The max. is 13 characters.
UNDER TEST: It sets as ON or OFF.
(1) When set as ON: UNDER TEST terminal on rear panel
is short-circuited condition under pause mode.
(2) When set as OFF: UNDER TEST terminal on rear
panel is open-circuited condition under pause mode.
TEST TIME : It sets the action method of pause mode.
(1) When set to CONTINUE, pause mode will be ended till
To Next Page
