HIPOT Tester 19071/19072/19073 User’s Manual
5-18
The setting meanings of HEX inputs are as the following:
0xAB = Header
0x01 = Destination Address
0x70 = Source Address
0x02 = Data Field Length
0x2E = Command Code
0x01 = “1”Go to Remote (Command Parameter)
0x5E = Checksum
The reading meanings of returning HEX code are as the following:
0xAB = Header
0x70 = Destination Address
0x01 = Source Address
0x02 = Data Field Length
0x7F = Reply Message Command Code
0x00 = Reply Message Return Data
0x0E = Checksum
Remote Status?
Description: It queries remote status of the device.
Command code: 0xAE
Parameter: None
Return data: 1 byte data
0: Local
1: Remote
2: Remote and Local Lockout
Example: Master (0x70): 0xAB 0x01 0x70 0x01 0xAE 0xE0
Slave (0x01): 0xAB 0x70 0x01 0x02 0xAE 0x01 0xDE
Descriptions of example
The setting meanings of HEX inputs are as the following:
0xAB = Header
0x01 = Destination Address
0x70 = Source Address
0x01 = Data Field Length
0xAE = Command Code
0xE0 = Checksum
The reading meanings of returning HEX code are as the following:
0xAB = Header
0x70 = Destination Address
0x01 = Source Address
0x02 = Data Field Length
0xAE = Command Code
0x01 = “1” Remote (Return Data)
0xDE = Checksum
Set C Standard
Description: It sets the standard capacitance of OS mode.
Command code: 0x2F
Parameter: 6 byte
