Chroma 3302 - Page 101

RS-232C Control Interface
8-3
*TRG Set group trigger
BIAS:ON Set BIAS on Only valid when DCA card is
connected
BIAS:OFF Set BIAS off
BIASIN3
Set BIAS test value
N3: 0.0 〜 1000.0 (mA)
BIASEN3
Set BIAS test value (external) N3: -100.0~+100.0 (A)
CKIT:PARALLEL,
CKIT:PARA
Set to equivalent circuit parallel
test mode
CKIT:SERIES, CKIT:SERI Set to equivalent circuit serial test
mode
CNST? Inquiry the current Constant setting
CNST:OFF Set Constant OFF
CNST:320X Set Constant to 320X
CNST:106X Set Constant to 106X
CNST:107X Set Constant to 107X
FREQ:STARTN3
Set the start value of internal
trigger frequency
N3: 0.02
〜
1000.0 KHz
FREQ:ENDN3
Set the end value of internal trigger
frequency
N3: 0.02
〜
1000.0 KHz
FREQ:STEPN3
Set the interval of internal trigger
frequency
FREQ:SCAN:YES Set the internal trigger to ON
FREQ:SCAN:NO Set the internal trigger to OFF
FREQN3
Set frequency
N3: 0.02
〜
1000.0 KHz
VOLTN3
Set voltage
N3: 0.01
〜
2.00V
PARA:LSD Set the parameter to Ls-D Serial inductance and
dissipation factor
PARA:LPD
Set the parameter to Lp-D Parallel inductance and
dissipation factor
PARA:LSQ
Set the parameter to Ls-Q Serial inductance and quality
factor
PARA:LPQ
Set the parameter to Lp-Q Parallel inductance and quality
factor
PARA:CSD
Set the parameter to Cs-D Serial capacitance and
dissipation factor
PARA:CPD
Set the parameter to Cp-D Parallel capacitance and
dissipation factor
PARA:CSQ
Set the parameter to Cs-Q Serial capacitance and quality
factor
PARA:CPQ
Set the parameter to Cp-Q Parallel capacitance and quali
ty
factor
PARA:LSRS
Set the parameter to Ls-Rs Serial inductance and serial
resistance
PARA:CSRS
Set the parameter to Cs-Rs Serial capacitance and serial
resistance
PARA:LPRP Set the parameter to Lp-Rp
Parallel inductance and parall
el
resistance
