High Power DC Electronic Load 63200 Series Operation & Programming Manual
VOLTS
AMPS WATTS/OHMS
CP
CV
CR
CC
CURSOR
GO/NG
7
4
1
0
.
2
5
8
9
6
3
EDIT
16V/80V
MODEL
60A/600ADC ELECTRONIC LOAD
63203
4KW
5.2KW
Figure 3-1 The Front Panel
3.3 Rear Panel Description
The Mainframe rear panel includes ports of RS-232C, RS485, GPIB, two remote sense, three
BNC connectors, a pair of input terminals, an AC LINE socket, and a fuse holder. Figure
3-2 shows the rear panel of Mainframe 63200.
3-2
