Local Operation
4. Set Voltage spec
Set the high voltage spec. to 6 V by pressing 6 , ENTER.
CRH VOLTAGE SPEC.
HIGH : 6.000V
Set the low voltage spec. to 4 V by pressing 4 , ENTER.
CRH VOLTAGE SPEC.
LOW : 4.000V
Then the display will go to the first editing page again.
Setting CV Values
The CV mode for the Load is programmed by pressing CV. The voltage values can be
programmed in low voltage (CVL) or high voltage (CVH) range. The current is always in
high range. All voltage levels are programmed in Volt.
The following examples illustrate how to set CV values for Load model number 63203.
1. Select range
Press RANGE key to choose the low range CV mode.
CVLA : 16.000V
CVLB : 16.000V
If press RANGE again, it will go back to the high range CV mode.
2. Set voltage Level
Set level A voltage level to 10 V by pressing 1, 0, ENTER.
Set level B voltage level to 8 V by pressing 8, ENTER.
CVLA : 10.000V
CVLB : 8.000V
3. Set Response Speed
There are two response speeds for CV mode, fast and slow for different UUT testing.
Refer to Figure 4-2 and 4-3 for transfer functions.
4-7
