Chroma 69225 Series User Manual

Overview
1-5
Model
69225-200-4
69225-500-4
Channel
4
4
Charge Mode
Voltage Range
0-200Vdc
0-500Vdc **
Maximum Current
30A
13A
Max Power
2.5KW
2.5KW
CC Mode Accuracy
0.1% stg.+ 0.05% F.S.
0.1% stg.+ 0.05% F.S.
Current Resolution
5mA
1mA
CV Mode Accuracy
0.1% stg.+ 0.05% F.S.
0.1% stg.+ 0.05% F.S.
Voltage Resolution
5mV
5mV
CP Mode Accuracy
0.2% stg.+ 0.1% F.S.
0.2% stg.+ 0.1% F.S.
Power Resolution
0.5W
0.5W
Discharge Mode
Voltage Range *
0-200Vdc
0-500Vdc **
Maximum Current
30A
13A
Max Power
2.5KW
2.5KW
CC Mode Accuracy
0.1% stg.+ 0.05% F.S.
0.1% stg.+ 0.05% F.S.
Current Resolution
5mA
1mA
CV Mode Accuracy
0.1% stg.+ 0.05% F.S.
0.1% stg.+ 0.05% F.S.
Voltage Resolution
5mV
5mV
CP Mode Accuracy
0.2% stg.+ 0.1% F.S.
0.2% stg.+ 0.1% F.S.
Power Resolution
0.5W
0.5W
Measurement
Voltage Range
0-200Vdc
0-500Vdc
Voltage Accuracy
0.02% rdg.+ 0.02% F.S.
0.02% rdg.+ 0.02% F.S.
Voltage Resolution
5mV
5mV
Current Range
12A/30A
4.8A/13A
Current Accuracy
0.05% rdg.+ 0.05% rng.
0.1% rdg.+ 0.05% rng.
Current Resolution
3mA
1mA
Power Range
2500W
2500W
Power Accuracy
0.07% rdg.+ 0.07% F.S.
0.12% rdg.+ 0.07% F.S.
Power Resolution
0.3W
0.3W
Temperature Range
0-90°C
0-90°C
Temperature Accuracy
±2°C
±2°C
Temperature Resolution
0.1°C
0.1°C
Note
* 0V discharge definition and charge/discharge operation range are as Figure 1-1
and Figure 1-2 shown.
** Voltage range is 45-500VDC when model 500V is operated in battery simulator.
V-I operation ranges of 69225/69212 series are shown as the following table. It is drawn by
the data gotten by the experiment of 5m length output wire.
