Chroma 69225 Series User Manual

Regenerative Charge/Discharge Tester 69225/69212 Series User’s Manual
2-2
*Remote Connector 4
Voltage connector for measuring
line (male)
Applicable models: 69212-20-4,
69212-60-4, 69225-60-4,
69225-100-4, 69225-200-4
**Remote Connector 4
Voltage connector for measuring
line (male)
Applicable models: 69225-500-4
Termination accessory 1
DSUB 15pin male connector
User’s Manual CD 1
CD for user’s manuals in English
and Traditional Chinese
hoop 12
It is used to fix wire on rear panel
(parallel channel used
communication line and
temperature communication line).
Protection cover for
output terminal
8
It can be locked while output
terminal unused.
Screw for output
terminal protection
cover
16
It is for locking protection cover.
Protection cover for DC
BUS input terminal
2
It can be mounted while input
terminal unused.
Optional accessory items:
Table 2-2
No.
Item
Drawing
Description
1 A692003
Temp sensor + temp
communication line
