Display Page
MENU Description Displays Security
PROC Process Variable Sensor Span A
L SP Limit Setpoint Sensor Span
LOUT Limit Output ON/OFF
TOSP Time Over Setpoint 0 TO 999.9 MIN
PEAH Peak Temperature Instrument Sensor Span
ALR Alarm Output Status NONE = No alarms
AL 1 = Alarm #1
AL 2 = Alarm #2
AL12 = Alarm #1 and #2
The Display Page is for status only. None
of the settings can be changed.
SET
PAGE
▲▼
RESET
SET Page
MENU Description Available Settings Security
LOCH Security Lock 0 to 9999 A
L SP Limit Setpoint Instrument Sensor Span C
DB Limit Dead Band 0 to 100 C
ENTI Event Input Function NONE = Disabled D
ALR = Alarm Reset
AOUT Analog Output Enable NONE = Disabled
PROC = Process Variable
CONT Controller Type HI
LO
CODE User Security Code 0 to 999
0-122 = Security level A
123-457 = Security level B
458-735 = Security level C
736-999 = Security level D
A LO Ambient Temperature Low -3 to 153
A HI Ambient Temperature High -3 to 153
LDSP Lower Display Disable ON = Enabled
OFF = Disabled
VIEW
DATA
VIEW
DATA
20
29
