Chromalox 3101 Operator's Manual 25
Input Page
MENU Description Available Settings Security
SENS Sensor Type Sensor Type selected here must C
agree with dip switch settings.
J = J Thermocouple
H = K Thermocouple
T = T Thermocouple
E = E Thermocouple
R = R Thermocouple
S = S Thermocouple
B = B Thermocouple
RTD = 100 Pt RTD (α = .00385)
4-20 = 4 to 20mA
0-5 = 0 to 5 Vdc
1-5 = 1 to 5 Vdc
UNIT Display Units NONE = none (analog inputs)
°F = Degrees Fahrenheit
°C = Degrees Celsius
COFF Calibration Offset 0 to ±100°F
(±6.25% of span for analog inputs)
SPLL Setpoint Low Limit Instrument Sensor Span
SPUL Setpoint Upper Limit Instrument Sensor Span
CALS Sensor Calibration INLO = Input low D
INHI = Input high
DONE = Calibration fi nished
AO 0 Analog Output Zero 0 to 4095
Calibration
AO S Analog Output Span 0 to 4095
RECC Factory Calibration Recovery RDY = Ready
---- = Wait
DONE = Finished
INPT
PAGE
▲▼
RESET
VIEW
DATA
4
56
