Chromalox 3101 Operator's Manual 55
Analog
Output
Option
Calibration
(continued)
3. Adjust the setpoint to the high end of span.
4. Go to menu AO S. Adjust the value in the lower
display until the meter reads 20mA or 5.000 Vdc.
Factory
Calibration
Recovery
This option allows you to return the controller to
its factory calibration settings in the event that it
is severely out of calibration due to poor tech-
nique or unauthorized calibration. Although the
factory calibration settings are recovered, this
does not guarantee original calibration accuracy.
The Factory Calibration Recovery should be used
as a “starting point” for recalibration, should the
unit become severely out of calibration.
Factory Calibration Recovery is performed on
the INPT PAGE, menu RECC.
RECC
RDY
▲▼
RESET
VIEW
DATA
AO S
3902
▲▼
RESET
☛
VIEW
DATA
5. Press and hold
RESET
for 3 seconds to exit
calibration mode.
