70 Chromalox 3101 Operator's Manual
Alarm #2 Page
See page 27 for details.
Alarm #2 Page
MENU Description Available Settings Factory Settings Security
EN 2 Alarm 2 Enable OFF = Disabled OFF C
ON = Enabled
TYP2 Alarm 2 Type NONE = Disabled (off) NONE
HI = High Alm
LO = Low Alm
HILO = High-Low Alm
PDE = Plus Deviation Alm
-DE = Minus Deviation Alm
DE = Plus/Minus Dev Alm
RLY2 Alarm 2 Relay NDE = normally de-energized NDE
non-latching
NE = normally energized
non-latching
NDEL = normally de-energized
latching
NEL = normally energized
latching
ALO2 Alarm 2 Low Setpoint Instrument Sensor Span Span Low
AHI2 2 High Setpoint Instrument Sensor Span Span High
DB2 Output 2 Dead Band 0 to 100°F 1°F
(Alarm Hysteresis) (.00 to 6.25% of span for
analog inputs)
INH2 Alarm 2 Inhibit OFF OFF
ON
