8.4 Factory-set parameters
Menu
[4-Machine parameters]
The parameters of the [4-Machine parameters] menu contains the parameters used to configure the machine. They were set in
the factory and are locked. The symbol appears at the top left of the screen.
In certain rare cases (such as adding the misting function), it may be necessary to update a parameter. The parameters may be
unlocked by changing parameter A99. However, do not modify any parameters other than those that require changing.
Parameter No. Parameter description Display condition
A01 Unit type (flatbed or V-coil)
A02
Number of coils (1) Flatbed unit
Parallel coil (no) V-type unit
A03
Type of coil 1
(1 refrig. circuit, 2 refrig. circuits)
A04 Coil circuit type (balanced or unbalanced) Flatbed unit & 2 refrigerant circuits
A05 Coil 2 type (1 refrigerant circuit) V-type unit
A07 Control type: On/Off (stages), speed control or mixed
A08 Number of stages (1 to 6) Control = On/Off or mixed
A09 Number of fan lines (1 or 2) Flatbed unit & 2 refrigerant circuits
A10 Misting (yes or no)
From V07
A15.1 Measurement of electrical quantities
A15.2 NET electrical network type A15.1 = YES
A16 Primary current transformer rating A15.1 = YES
A17 Secondary current transformer rating A15.1 = YES
A30 Top of sensor range - circuit or coil 1
A31 Bottom of sensor range - circuit or coil 1
A32 Top of sensor range - circuit 2 2 refrig. circuits
A33 Bottom of sensor range - circuit 2 2 refrig. circuits
A34 Top of sensor range - coil 2 2 refrig. circuits
A35 Bottom of sensor range - coil 2 2 refrig. circuits
A99 Lock parameters (yes)
9 - CMS COMMUNICATION PROTOCOL
9.1 Communication interface
[11- Communication]
Parameter No. Description Default values
A700 RS485 communication protocol MODBUS
A701 Communication speed 9600 baud
A702 Parity None
A703 Number of Stop bits 1
A704 Real number format swapped for RS485 NO
A705 Bus number 1
A706 RS485 control type Local
A710 TCP communication protocol MODBUS
A711 IP address 192.168.10.2
A712 Subnet mask 255.255.255.000
A713 Port 502
A714 Real number format swapped for TCP NO
A715 TCP control type Local
