Registers 578 and 579: A113: Misting control voltage threshold
Register 580: A129 Permanent fan fault
0 5 faults in 1 hour
1 After first fault
Register 581: A109 Operation
0 Cooling
1 Warming without control
2 Warming with control
Register 582 and 583: A109.1: Outdoor temperature warming operating order
Register 584 and 585: A105 : Threshold mini of fan speed in mixed control 3
9.9 Function 1, 2: read N bits
9.9.1 Remote alarm and operating state
(1 = Fault)
Bit 1: Fan fault, stage 1, line 1
Bit 2: Fan fault, stage 2, line 1
Bit 3: Fan fault, stage 3, line 1
Bit 4: Fan fault, stage 4, line 1
Bit 5: Fan fault, stage 5, line 1
Bit 6: Fan fault, stage 6, line 1 or fan fault stage 7, line 1
Bit 7: Fan fault, stage 1, line 2
Bit 8: Fan fault, stage 2, line 2
Bit 9: Fan fault, stage 3, line 2
Bit 10: Fan fault, stage 4, line 2
Bit 11: Fan fault, stage 5, line 2
Bit 12: Fan fault, stage 6, line 2
Bit 13: Pressure or temperature sensor fault, coil 1, circuit
(from V07)
Bit 14: Temperature sensor or pressure fault, coil 1, circuit 2
Bit 15: Temperature sensor or pressure fault, coil 2, circuit 1
Bit 16: Temperature sensor or pressure fault, coil 2, circuit 2
Bit 17: On/off (1 = on on and AOC closed)
Bit 18: Spray state 1 = on
Bit 19: Free cooling state 1 = on
Bit 20: General fault summary
Bit 21: Connection fault with the Diris module
9.9.2 Remote control
Read and write
Bit 31: On/off (0 = off, 1 = on)
Bit 32: Setpoint 1/setpoint 2 control (0 = Setpoint 1, 1 = Setpoint 2)
9.9.3 Status of the fan outputs
Read-only
Bit 40: Fan state, stage 1, line 1 (1 = on)
Bit 41: Fan state, stage 2, line 1 (1 = on)
Bit 42: Fan state, stage 3, line 1 (1 = on)
Bit 43: Fan state, stage 4, line 1 (1 = on)
Bit 44: Fan state, stage 5, line 1 (1 = on)
Bit 45: Fan state, stage 6, line 1 (1 = on)
Bit 46: Fan state, stage 1, line 2 (1 = on)
Bit 47: Fan state, stage 2, line 2 (1 = on)
Bit 48: Fan state, stage 3, line 2 (1 = on)
Bit 49: Fan state, stage 4, line 2 (1 = on)
Bit 50: Fan state, stage 5, line 2 (1 = on)
Bit 51: Fan state, stage 6, line 2 (1 = on)
Bit 52: Fan state, stage 7, line 1 (1 = on)
Bit 53: Fan fault, stage 7, line 1
9.9.4 Remote diagnostic Function 8
Read-only
Sub-function 0A: Reset counters (No reply)
Sub-function 0B: Frame received without CRC errors
Sub-function 0C: Frame received with CRC errors
Sub-function 0D: Number of exception replies
Sub-function 0E: Frames sent excluding broadcast
Sub-function 0F: Broadcast request received
Sub-function 10: N.U.
Sub-function 12: Unprocessed character
9.9.5 Function 11 Event counters
Read-only
