EN7510364-00
EN - 28
9.4 Remote alarm register (read-only)
Register 10: FAN FAULTS (1 = active fault)
Bit Bit
0 Fan fault, stage 1, line 1 8 Fan fault, stage 1, line 2
1 Fan fault, stage 2, line 1 9 Fan fault, stage 2, line 2
2 Fan fault, stage 3, line 1 10 Fan fault, stage 3, line 2
3 Fan fault, stage 4, line 1 11 Fan fault, stage 4, line 2
4 Fan fault, stage 5, line 1 12 Fan fault, stage 5, line 2
5 Fan fault, stage 6, line 1 13 Fan fault, stage 6, line 2
6 Fan fault, stage 7, line 1 14 N.U.
7 N.U. 15 N.U.
Register 11: SENSOR FAULT (1 = active fault)
Bit Bit
0 Pressure or temperature sensor fault, coil 1, circuit 1 8 Pressure or temperature sensor fault, coil 2, circuit 1
1 Pressure or temperature sensor fault, coil 1, circuit 2 9 Pressure or temperature sensor fault, coil 2, circuit 2
2 N.U. 10 N.U.
3 N.U. 11 N.U.
4 N.U. 12 N.U.
5 N.U. 13 N.U.
6 N.U. 14 N.U.
7 N.U. 15 N.U.
9.5 Remote measurement register (read-only)
Register Float type Register Float type
100 and 101 Setpoint and control coil 1, circuit 1 116 and 117 Outdoor temperature
102 and 103 Control setpoint, coil 1, circuit 2 118 and 119 Voltage between phase 1 and 2
104 and 105 Control setpoint, coil 2, circuit 1 120 and 121 Voltage between phase 2 and 3
106 and 107 Control setpoint, coil 2, circuit 2 122 and 123 Voltage between phase 1 and 3
108 and 109 Temperature or pressure, coil 1, circuit 1 124 and 125 A471 Input current
110 and 111 Temperature or pressure, coil 1, circuit 2 126 and 127 A472 Instantaneous power consumed
112 and 113 Temperature or pressure, coil 2, circuit 1 128 and 129 Total energy consumed kW/h (write 0 to reset the value)
114 and 115 Temperature or pressure, coil 2, circuit 2
9.6 Fault memory
Register 200: Fault memory 9
Register 201: Fault memory 8
Register 202: Fault memory 7
Register 203: Fault memory 6
Register 204: Fault memory 5
Register 205: Fault memory 4
Register 206: Fault memory 3
Register 207: Fault memory 2
Register 208: Fault memory 1
0: Fault memory empty
0x010: Fan fault, stage 1, line 1
0x011: Fan fault, stage 2, line 1
0x012: Fan fault, stage 3, line 1
0x013: Fan fault, stage 4, line 1
0x014: Fan fault, stage 5, line 1
0x015: Fan fault, stage 6, line 1
0x016: Fan fault, stage 1, line 2
0x017: Fan fault, stage 2, line 2
0x018: Fan fault, stage 3, line 2
0x019: Fan fault, stage 4, line 2
0x01A: Fan fault, stage 5, line 2
0x01B: Fan fault, stage 6, line 2
0x01C: Outdoor temperature sensor fault
0x01D: Fan fault, stage 7, line 1
0x080: Temperature sensor fault, coil 1, circuit 1
0x081: Temperature sensor fault, coil 1, circuit 2
0x082: Temperature sensor fault, coil 2, circuit 1
0x083: Temperature sensor fault, coil 2, circuit 2
0x084: Pressure sensor fault, coil 1, circuit 1
0x085: Pressure sensor fault, coil 1, circuit 2
0x086: Pressure sensor fault, coil 2, circuit 1
0x087: Pressure sensor fault, coil 2, circuit 2
