46
Circuit 2 liquid temperature:
Circuit 2 subcooling value:
Number of cut-offs caused by circuit 2 expansion valve fault:
Inputs:
State of unit automatic operation control input:
State of setpoint selection input (1 or 2):
State of water flow fault input:
State of fan fault input:
State of operating mode selection input:
State of phase controller fault input:
State of recovery operating mode selection input:
State of fault input 1 on ADDitional board 1 for units equipped with auxiliary electric heaters P22 = Yes:
State of fault input 2 on ADDitional board 1 for units equipped with auxiliary electric heaters P22 = Yes:
State of configurable input on ADDitional board 1 for units equipped with auxiliary electric heaters P22 = Yes and P113 = load shedding or forced:
P 3 5 6 C I R C U I T 2
L I Q U I D T E M P . x x . x °
P 3 5 7 C I R C U I T 2
S U B C O O L I N G x x . x °
P 3 5 8 N O . C U T O F F S C A U S E D
B Y C 2 E X V I N 2 4 H X
P 4 0 0 A U T O . O P E R A T I O N
C T R L I N P U T O P E N
P 4 0 2 S E T P O I N T S E L E C T I O N
I N P U T 1
P 4 0 3 W A T E R F L O W
F A U L T I N P U T O P E N
P 4 0 4 F A N F A U L T
I N P U T O P E N
P 4 0 5 H E A T I N G / C O O L I N G
M O D E I N P U T O P E N
P 4 0 6 P H A S E C O N T R O L L E R
F A U L T I N P U T O P E N
P 4 0 7 R E C O V E R Y O P E R A T I O N
I N P U T O P E N
P 4 0 8 F A U L T I N P U T 1
E L E C T R I C A D D 1 O P E N
P 4 0 9 F A U L T I N P U T 2
E L E C T R I C A D D 1 O P E N
P 4 1 0 C O N F I G U R A B L E I N P U T
E L E C T R I C A D D 1 O P E N
