CIAT Connect 2 - TEST MODE Menu

51
Reading for saving faults to memory:
Reading if a circuit fault occurs: information on circuit that cut off
If a unit fault occurs:
8.9 TEST MODE menu
TEST MODE is used to shorten time delays and eliminate limits (but keep the protections on).
The other menus (measured values, parameters, fault memory, etc.) can be accessed while in test mode.
When test mode is on for a circuit, the Voltage LED flashes quickly (the same LED on the remote control console flashes).
To turn on test mode:
 Via menu 8.
Select YES or NO with the + and – buttons. Press OK to confirm your choice.
To turn off test mode:
 Select NO in the submenu of menu 8 or wait 1 hour for test mode to turn off (NO) automatically.
Test mode remains on for 1 hour.
x - C O N D E N S E R I N S E N S O R
x - C O N D E N S E R O U T S E N S O R
x - C I R x C O I L A S E N S O R
x - D I S C H . S E N S O R x
x - M A N I F . H 2 O S E N S O R
x - E X C H . A M B . S E N S O R
x - S U C T I O N S E N S O R
x - L P S E N S O R x
x - H P S E N S O R x
x - P U M P X
x - P U M P S 1 A N D 2
x - S E L F - A D J C T R L
x - C I R C U I T x D E F R O S T
x - C X E X P . V A L V E
x - E X P . V A L V E X L I N K
x - E X C H . F R O S T P R O T . x
F A U L T M E M O R Y E M P T Y
H P X : x x x . x b T C O N D : + x x . x ° ↑
L P x : x x x . x b T E V A P : + x x . x °
S U C T I O N T . x : + x x . x °
S U P E R H E A T x : x x . x ° ↓
D I S . T 1 : x x x ° D I S . T 2 : x x x ° ↑
W A T E R I N L E T : - x x . x °
W A T E R O U T L E T : - x x . x °
O U T D O O R T.:- x x . x ° ↓
R E F R I G . T . x + x x . x ° ↑
H O T W A T E R T . - x x . x
O U T D O O R T . : - x x . x ° ↑
C T R L S E T P O I N T : - x x . x °
W A T E R I N L E T : - x x . x °
M A N . W A T E R O U T : x x . x ° ↓
H O T W A T E R T . - x x . x ° ↑
T E S T M O D E
Y E S
T E S T M O D E
N O
Manifold water
outlets (if two
circuits) or water
outlet 1 (if one
circuit)
