21
- Menu 13 allows all information about AEROCONNECT to be displayed on the CONNECT 2 console without having to use the AEROCONNECT
console.
- The AERO-CONNECT parameters are preceded by the letter A to differentiate them from the CONNECT 2 parameters.
- If a dry cooler equipped with its AERO-CONNECT console is connected to CONNECT 2 and P116 is set to Yes, neither console has priority over the other.
- If menu 13 remains open for 1 hour and no buttons are pressed during this time, the screen switches to the CONNECT 2 display.
- Parameter A99 (lock parameters) cannot be set to No via the CONNECT 2 console.
- Parameter A116 (CIAT CW unit link) is not accessible via the CONNECT 2 console because setting A116 to No will delete the link with the console.
- Parameter A250 is not accessible because the LED test on the CONNECT 2 console is performed via parameter P250 on CONNECT 2.
- The forced fan operation function on the console is not accessible via the CONNECT 2 console.
8 CONTENTS OF THE MENUS
The ° symbol stands for °C in the electronic programming system.
Analogue values are displayed with one decimal place. The hundreds digit may be replaced by a negative sign when appropriate.
A selection symbol flashes at the left of the display.
Holding down the + or - buttons will cause increasingly faster scrolling (and change the units) in the list of parameters or when modifying
parameter values.
8.1 MAIN menu
Scrolling through menus occurs line by line.
The + button is used to increment values and the - button is used to decrement values.
The first square at the top left flashes.
8.2 SETPOINTS menu
This menu gives quick access to settings for the control setpoints depending on the control mode and the selected operating mode.
To move from parameter to parameter, press the + or buttons. The letter P flashes when a parameter is selected.
To change the value of a selected parameter, press OK. The value can be changed when the cursor flashes at the bottom right. Use the +
button to raise the value, and the - button to lower it. When finished, press OK to confirm or ESC to cancel the changes.
When returning to menu 1 the last parameter consulted is displayed.
1 - S E T P O I N T S
2 - S T A T U S O F M A C H I N E S
3 - M E A S U R E D V A L U E S
4 - M A C H I N E . P A R A M E T E R S
5 - A D J U S T M E N T . P A R A M E T E R S
6 - R E A D I N G . P A R A M E T E R S
7 - F A U L T M E M O R Y
8 - T E S T M O D E
9 - P R O G R A M M I N G
10- E L E C T R O E X P A N S I O N V AL
11- COM M U N I C A T I ON
12- M A S T E R / S L A V E
13- A E R O - C O N N E C T
14- ACC E S S L E V E L S E L E C T .
P x x x S T P 1 C O O L I N G
- x x . x °
P x x x S T P 2 C O O L I N G
- x x . x °
P x x x : S T P 1 H E A T I N G
- x x . x °
P x x x : S T P 2 H E A T I N G
- x x . x °
If P119 heating
If P120 = 2 and if P119 heating
If P119 cooling
If P120 = 2 and P119 cooling
