HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.122 H
Water chillers and
air-water heat pumps
9
CIATCooler LP
4. TECHNICAL CHARACTERISTICS
STD version with pump included
European Seasonal Energy Effi ciency Ratio (ESEER) obtained in accordance with the calculation conditions established by the certifi cation body EUROVENT.
Values calculated in accordance with the EN-14825-2013 standard given for bivalente temperature of -5ºC in average climate and 2ºC in warmer climate.
The water capacity for the installation indicated in this table corresponds to the maximum that the installation allows based on the expansion vessel assembled on the unit.
The volume of the buffer tank has been taken into account for this section. In case the capacity of the installation is greater, it is necessary to add a supplementary expansion
vessel to the installation based on its volume.
This temperature corresponds to the temperature that the circuit may reach when the unit is stopped. This case must be considered for cooling-only units.
This temperature corresponds to the maximum temperature that the circuit may reach when operating in a heat pump.
Minimum distance between the unit and the separte hydraulic module: 167 mm.
CIATCooler LPC / ILPC
90V-
STD
100V-
STD
120V-
STD
160V-
STD
180V-
STD
200V-
STD
240V-
STD
280V-
STD
320V-
STD
360V-
STD
Cooling
Seasonal effi ciency
ESEER 2,67 2,61 2,89 2,97 2,84 2,73 2,99 2,99 3,29 3,17
Heating
Seasonal effi ciency
Average climate
SCOP 3,24 3,13 3,10 2,95 3,06 2,96 3,10 2,95 2,96 3,02
ŋs Heat 126% 122% 121% 115% 119% 115% 121% 115% 115% 118%
Prated (kW) 16,83 19,20 21,83 26,21 30,53 38,31 41,45 44,73 51,02 65,65
Seasonal effi ciency
Warmer climate
SCOP 3,82 3,60 3,60 3,44 3,57 3,35 3,74 3,56 3,55 3,40
ŋs Heat 150% 141% 141% 135% 140% 131% 147% 139% 139% 133%
Prated (kW) 12,77 14,71 16,72 24,22 27,28 34,73 39,27 42,59 46,95 58,15
Indoor
circuit
Nominal water fl ow (m
3
/h) 3,1 3,7 4,3 5,7 6,2 7,5 8,5 9,6 11,7 12,8
Pressure drop (m.w.c.) 3,1 4,2 3,8 6,2 4,5 4,9 4,1 5,1 3,5 4,3
Expansion
vessel
Volume (l) 12 20
Filled pressure (kg/cm
2
) 1,5
Buffer tank
(LPC / ILPC
+ module)
Volume of the buffer tank (l) 100 150 225
Maximum water capacity
of the installation
Water 40ºC (l)
700 650 1100
Water 50ºC (l)
410 360 625
Drained diameter 3/4” M 1” M
Anti-freeze elec. heater
(standard)
Voltage 230 V / I ph
Output (kW) 1 kW (4,3 A)
Dimensions
Length (mm)
LPC / ILPC 1117 1398 2113 2673
Module 1000 1000 1000 1000
Width (mm) 860 860 860 860
Height (mm) 1447 1727 1447 1727
Weight
LPC / ILPC
Empty (kg) 318 328 390 408 408 586 666 700 736 741
In operation (kg) 335 345 410 428 429 622 702 736 774 780
Hydraulic
module
Empty (kg) 139 139 161 161 161 161 169 169 169 169
In operation (kg) 242 242 315 315 315 393 404 404 404 404
CIATCooler LPC / ILPC
420V-
STD
480V-
STD
600V-
STD
640V-
STD
720V-
STD
840V-
STD
960V-
STD
Cooling
Seasonal effi ciency
ESEER 3,13 3,07 3,02 3,00 2,87 3,04 2,89
Heating
Seasonal effi ciency
Average climate
SCOP 2,95 3,04 3,09 2,95 2,95 3,10 3,21
ŋs Heat 115% 119% 120% 115% 115% 121% 126%
Prated (kW) 82,76 90,84 111,30 118,94 137,14 159,98 175,15
Seasonal effi ciency
Warmer climate
SCOP 3,29 3,61 3,34 3,42 3,34 3,46 3,68
ŋs Heat 129% 141% 131% 134% 131% 135% 144%
Prated (kW) 70,59 77,41 95,09 102,06 116,45 137,01 148,68
Indoor
circuit
Nominal water fl ow (m
3
/h) 15,3 16,7 20,5 23,2 26,2 30,5 33,1
Pressure drop (m.w.c.) 7,5 8,8 11,1 10,8 13,3 12,9 15,1
Expansion
vessel
Volume (l) 35 50
Filled pressure (kg/cm
2
) 1,5
Buffer tank
(LPC / ILPC
+ module)
Volume of the buffer tank (l) 275 275 375
Maximum water capacity
of the installation
Water 40ºC (l)
2050 3035 2985
Water 50ºC (l)
1210 1840 1790
Drained diameter 1” M
Anti-freeze elec. heater
(standard)
Voltage 230 V / I ph
Output (kW) 1 kW (4,3 A)
Dimensions
Length (mm)
LPC / ILPC 3400 3600 4500
Module 1000 1000 1000
Width (mm) 900 1150 1200
Height (mm) 1970 1970 1970
Weight
LPC / ILPC
Empty (kg) 1107 1183 1272 1512 1523 2038 2189
In operation (kg) 1169 1246 1336 1592 1603 2131 2282
Hydraulic
module
Empty (kg) 202 202 202 241 241 263 263
In operation (kg) 486 486 486 544 544 668 668
