2-6 Installation
3902 Service Delivery Switch Hardware Installation and Start-up Manual
009-3205-001 Standard Revision D
Copyright
©
2013-2015 Ciena
®
Corporation July 2015
• 10/100/1000 Mbps Port
• 1G Port when a copper SFP is installed
To install an Ethernet cable, insert the connector into the port on the device
until you hear a clicking sound. Insert the tail end of the cable into the port on
the terminating device.
Initial configuration
Two different methods can be used to assign an IP address to the device:
• using a DHCP server to automatically assign an IP address
(recommended)
• configuring an IP address manually.
Both methods are accomplished through the CLI and are not described in this
document. For detailed instructions, see 39XX/51XX Configuration.
Note: If the device has not been assigned an IP address (either manually
or through a DHCP server) other than the default IP address,
communication can only take place through the console port. Initial IP
configuration must be done using the console port.
CAUTION
Use caution when setting the IP address or subnet mask, the
new value takes effect immediately. If information is set that is
inconsistent with network settings, communication to the
device may no longer be possible. If all other troubleshooting
methods have been exhausted, recovery may be possible
using the Reset button.
