SYSTEM DIAGRAMS
REFRIGERATION SCHEMATIC SYMBOLS
Figure 9-2: Symbols used on Refrigeration Diagrams (Continued)
WATER REGULATING VALVE
HIGH-PRESSURE REFRIGERANT ACTUATED HEAT EXCHANGER REFRIGERANT EVAPORATOR
COMPRESSOR SERVICE VALVE
VIBRATION ELIMINATOR
HEAT EXCHANGER REFRIGERANT EVAPORATOR
WITH DISTRIBUTOR
PIPING CONTINUATION ARROW
BALL VALVE
TEMPERATURE MONITORING
THERMOCOUPLE
HEATER STRAINER (WATER INLET)
(CRANKCASE HEATER, RECEIVER HEATER)
