SYSTEM DIAGRAMS
REFRIGERATION SCHEMATIC SYMBOLS
Figure 9-2: Symbols used on Refrigeration Diagrams (Continued)
HERMETIC SCROLL COMPRESSOR - K4 SERIES HERMETIC RECIPROCATING COMPRESSOR
SEMI-HERMETIC RECIPROCATING
COMPRESSOR
SEMI-HERMETIC RECIPROCATING COMPRESSOR
(2-3 CYLINDERS) (6 CYLINDERS)
SEMI-HERMETIC RECIPROCATING
COMPRESSOR
(4 CYLINDERS)
