Cinderella FREEDOM - Inlet Air Requirements

12
2.4 INLET AIR
It is required to install adequate venting in accordance with AS/NZS 5601.1. The air inlet vent should preferably
be installed as close to the Cinderella toilet as possible, to ensure a good air supply to the toilet and reduce the
environmental impact in the toilet room. It is important that there are no other air-dependent installations used
at the same time as the toilet, e.g. an extractor fan or replace. The Cinderella Freedom toilet draws air mainly
from the underside of the toilet. It is therefore possible to have the air intake underneath the toilet. This allows
you to insulate the air as much as possible in the toilet and minimise the environmental impact in the toilet
room.
50 mm
OPEN
NB!
The inlet vent’s minimum dimensions must be 160 mm (diameter)/ 201 cm². We
recommend that you use the supplied vent.
• The vent must be open at all times. Remember to clean the vent at regular intervals.
• Make sure that there is no conict between the toilet’s air supply and other
installations, such as a replace or extractor fan.
• Do not use a separate ventilation fan or similar to extract air from the room where the
toilet is installed when using the Cinderella Freedom toilet.
• If you have open ventilation under the toilet, it may be advisable to use a mesh over
the hole to keep insects and vermin from entering the toilet. Make sure that the mesh
is not too ne as this will impede the air ow.
NOTE!
The air inlet vent must always
remain open when using the
Cinderella toilet.
NOTE!
If the installed air vent has an
adjustable opening, always make
sure to leave it open by a mini-
mum of (50 mm) when operating
the toilet.
