CONTENTS
1. GENERAL SECTION 3
1.1 INTRODUCTION 3
1.2 APPLICATION ACCORDING TO REGULATIONS 3
1.3 OPERATING INSTRUCTIONS GUIDE 3
1.4 LIMITATION OF LIABILITY 3
1.5 LISTINGS AND CERTIFICATIONS 3
1.6 GENERAL SAFETY INSTRUCTIONS 4
1.7 APPLIANCE RATING PLATE 5
1.8 CINDERELLA ONLINE 5
1.9 UNPACKING THE TOILET AND ACCESSORIES 5
2. INSTALLATION SECTION 6
2.1 SECURING THE TOILET TO THE FLOOR 6
2.2 MEASUREMENT SPECIFICATIONS CINDERELLA FREEDOM 7
2.3 FLUE PIPE INSTALLATION 8
2.3.1 FLUE PIPE SPECIFICATION 9
2.3.2 HORIZONTAL FLUE PIPE SPECIFICATIONS 10
2.3.3 VERTICAL FLUE PIPE SPECIFICATIONS 11
2.4 INLET AIR 12
2.5 GAS INSTALLATION 13
2.6 ELECTRIC CONNECTION 14
2.7 CHECKLIST TO VERIFY THE COMPLETE INSTALLATION 14
2.8 PERFORMANCE TEST TO VERIFY THE SYSTEM FUNCTIONALITY 15
3. USER SECTION 16
3.1 INTENDED USE AND HANDLING 16
3.2 GENERAL SAFETY 16
3.3 SAFETY WHEN OPERATING WITH GAS 16
3.4 SAFE OPERATIONS 17
3.5 CINDERELLA FREEDOM SAFETY FEATURES 17
3.6 IMPORTANT USER INFORMATION 18
3.7 THE CONTROL PANEL 19
3.8 USING THE CINDERELLA FREEDOM TOILET 20
3.9 OPERATING THE FRONT COVER AND ASH CONTAINER 21
3.10 APPLIANCE ORIENTATION 22
4. GENERAL MAINTENANCE INSTRUCTIONS 22
4.1 END PRODUCT CHARACTERISTICS 23
4.2 CUSTOMER MAINTENANCE 23
4.2.1 EMPTYING AND CLEANING THE ASH CONTAINER 23
4.2.2 STEAM-CLEANING THE CATALYTIC CONVERTER 24
4.2.3 INSPECTING THE CATALYTIC CONVERTER 25
4.2.4 CLEANING THE BOWL 25
4.2.5 MAINTENANCE DURAVENT FLUE PIPE SYSTEM 26
4.3 PROFESSIONAL MAINTENANCE 26
4.3.1 RINSING THE EXHAUST SYSTEM AND CATALYTIC CONVERTER 26
5.0 TROUBLESHOOTING AND FAQ 27
5.1 TROUBLESHOOTING TABLE 28
6. REPAIRS AND SPARE PARTS 29
6.1 SPARE PARTS LIST 29
6.2 APPLIANCE PROCESS OVERVIEW 30
6.3 TECHNICAL ORIENTATION 30
6.4 WIRE DIAGRAM 31
7. WARRANTY 31
