14
12V WIRING GUIDE
Amps 1 m 2 m 5 m 6 m 8 m 10 m
4 2 mm² 2 mm² 2 mm² 4 mm² 4 mm² 4 mm²
When connecting the toilet to the mains DC power, take the following into consideration:
• Make sure the cable has sucient current rating for the expected load in the circuit, including a margin of
safety.
• Make sure the cable cross section is dimensioned for the intended cable run length, and that the cable will
not cause the voltage to drop.
• Always check the polarity of the cables before connecting as reverse polarity connection is not covered under
warranty.
NOTE!
• The connection cable must be laid in such a way that it does not come into contact with
sharp edges.
• Changes to the internal electrical installation or the connection cable must be
performed by a professional tradesman or a similarly qualied person in order to
prevent safety hazards.
CONTROL ITEMS CONFORMANCE
The complete installation is in accordance with AS/NZS 5601.1
The appliance is properly mounted to the oor
The gas connection is in accordance with the specications on the appliance rating plate
The appliance is installed with rigid gas pipes
The appliance is powered with 12V DC, min. 4A
The appliance is vented with DuraVent ue pipes
The supplied DuraVent ue terminal is used on the top of the ue pipe
The ue pipe is no longer than 4.5 m
The ue termination is no less than 1000 mm from the roof surface
There is adequate venting in the room in accordance with AS/NZS 5601.1
Safe draining is installed where condensation is likely to accumulate
2.7 CHECKLIST TO VERIFY COMPLETE INSTALLATION
Power requirements
INPUT CURRENT FUSE
12V DC (11 – 14.4V) 4 A 10 A
Power consumption
HIBERNATION MODE STANDBY MODE INCINERATING MODE
0.005 A 0.09 A 1.3 A
Connection polarity
CROSS SECTION POSITIVE NEGATIVE
2 mm² Red Black
The respective negative and positive cables of the DC connection must not be joined to one another in a
camper, as this can cause electrical interference and damage to electrical components. The 12V supply must
be connected on its own circuit direct to the battery, with a 10 A fuse at the start of the circuit. Use the 12V wire
guide to calculate the correct cable size according to the cable length.
2.6 ELECTRIC CONNECTION
The correct voltage, frequency and amperage must be supplied to the appliance from a dedicated, earthed
circuit that is protected by a properly sized circuit breaker. The proper voltage, frequency and amperage are
listed in this manual, and on the product rating plate on the back of the toilet. Please note: This toilet requires a
12V 4A DC supply. If you require to operate it from a 240V AC power point (GPO) please request the approved
power supply from your dealer.
