X1 Series Dental Unit -Operating Manual
Add: Building 6-1,Nansha Industrial Village Jiangli North Rd,Danzao Town, Nanhai District,Foshan ,Guangdong,China
www.cingol.com
Objects protrude into the movement range of the chair.
There is a risk of crushing the patient and damaging the objects.
Make sure that no objects such as e.g. windows, drawers or other
devices protrude into the movement range of the dental unit.
Chair interlock
As long as a treatment instrument is activated, all functions for moving
the patient chair disabled for safety reasons.
If chair movement is permanently blocked, please contact your service
engineer.
4.3.2 Armrest
The patient chair can be equipped with armrests on the left. The
armrest is stationary.
4.3.3 Adjusting the headrest
The headrest enables you to adjust the patient’s head in a way that
optimally supports viewing of hard-to-access areas of the patient’s
mouth.
Patient height adjustment
The headrest can be adjusted to the patient’s height by pulling out or
pushing in the headrest extension.
Setting the jaw position
The headrest enables you to change between the maxillary and
mandibular positions without adjusting the headrest extension.
1. Loosen the wrench (A) counterclockwise, the headrest is
unloaded.
2. Holding the headrest by hand, raise or lower it to the required
position.
3. Tighten the wrench (A) clockwise, the headrest is locked again.
