9 Overview of graphic symbols used
symbols
Definition
symbols
Definition
Chair Memory Position
Clockwise to increase
Choose doctor
Clockwise to reduce
Chair up
Caution electric shock
Chair down
Protective grounding
Backrest up
Caution, consult
accompanying documents
Backrest down
Type B applied parts
Entry/exit position
IP
Drop protection
Emergency position
Caution, hot surface
Dentist element up
Manufacturer
Dentist element down
Date of manufacture
X-ray viewer
Fragile-protect against
knocks
Operating light
Keep dry
Tumbler filling
Transport upright with the
arrow pointing upwards
Flushing (the cuspidor)
Attention
Heating
CE mark.
A product with this mark
meets the requirements of
the applicable EU directive.
Setting
clean-up position
!!1!D
Notice Mark
!
