Page #96 background imageLoading...
Page #96 background image
87
Chapte
r
3 Radios
Auth Server Type of authentication server being used for EAP authentication.
Value:
Type 1 Cisco Secure ACS or another server that uses
PEAPv1 for PEAP with EAP-MSCHAPV2
(PEAP-MSCHAP)
Type 2 A different authentication server, such as
Juniper Networks Steel Belted RADIUS, that
uses PEAPv0 for PEAP-MSCHAP
Default: Type 1
TTLS Inner Method Authentication method used within secure tunnel created by EAP-TTLS.
Value:
Auto-EAP Any available EAP method
MSCHAPV2
MSCHAP
PAP
CHAP
EAP-MSCHAPV2
Default: Auto-EAP
PMK Caching The type of Pairwise Master Key (PMK) caching to use with a WPA2
encryption type (alternative to WPA2 CCKM).
Value: Standard or OPMK (opportunistic PMK)
Default: Standard
TX Diversity How to handle antenna diversity when transmitting data to AP.
Value:
Main Only Use main antenna only
Aux Only Use auxiliary antenna only
On Use diversity
Default: On
RX Diversity How to handle antenna diversity when receiving data from AP.
Default: On-start on Main
This is a fixed setting; on startup, the main antenna is always used
Frag Thresh When packet size exceeds the set threshold, it becomes fragmented.
Value: 256 ~ 2346
Default: 2346 (bytes)
RTS Thresh When packet size exceeds the set threshold, RTS/CTS is required on link.
Value: 0 ~ 2347
Default: 2347 (bytes)
LED Indicates whether or not an LED is used.
Value: On, Off
Default: Off
Tray Icon Whether to enable the system tray icon or not.
Value: On, Off
Default: On
