----- Supply network analyzer CVM 96 Ethernet -------- ----- Page No. 24
Three-phase active power kW III
16
Three-phase cos ϕ Cos ϕ
19
Three-phase inductive power kvarL III
17
Three-phase power factor PF III
20
Three-phase capacitive
power
kvarC III
18
Frequency Hz
21
Active energy kWh
31
Ph-Ph voltage L1- L2 V 12
22
Reactive energy (inductive) kvarh. L
32
Ph-Ph voltage L2 - L3 V 23
23
Reactive energy (capacitive) kvarh. C
33
Ph-Ph voltage L3 - L1 V 31
24
Three phase apparent power kVA III
34
Power demand Pd
35
Power demand (L1) Pd
35*
Three-phase current AIII 36
Power demand (L2) Pd
42*
Neutral current I
N
37
Power demand (L3) Pd
43*
There are, besides, some parameters that refer to 3 phases at once. In case that any
of these parameter is selected, then the alarm will be activated always one phase
complies with alarm settings.
Parameter Symbol Code
Line-to-neutral voltages V1 or V2 or V3 90
Currents I1 or I2 or I3 91
Active powers kW1 or kW2 or kW3 92
Reactive powers kvar1 or kvar2 or kvar3 93
Power factors PF1 or PF2 or PF3 94
Line-to-line voltages V12 or V23 or V31 95
% THD V THDV1 or THDV2 or THDV3 96
% THD I THDI1 or THDI2 or THDI3 97
