a.- If an ENERGY parameter is chosen: kW.h (31), kvarh.L (32) or kvarh.C(33)
OUT 1 RELAY 1
PULS
xxxx
( kW / pulse (1)
(1) Value of energy in kW : four digits with floating decimal point
- SETUP procedure:
- "max" key: to modify the value of the blinking value.
Every time it is pressed the value is increased.
- "min" key: to validate the blinking value and go to the next digit.
NOTE : When the last digit is reached, the position of the decimal can be move
point with the "max" key.
Example for setting a 500 W / 1 pulse:
Firstly we enter the value, 0500, and following we place the decimal point at
the right position with the "max" key Î 0.500 kW.
