----- Supply network analyzer CVM 96 Ethernet -------- ----- Page No. 26
- For accessing to the next option, press " ": SETUP options for the second relay
will appear (only with CVM 96...-C2).
OUT 2 RELAY 2
CODE
00
( Parameter value (2)
Act as before. Pressing again " " the SETUP mode is exited.
b.- ALARM conditions (1 condition for each relay): If any other parameter (1 to 30)
is selected at (1), two outputs can be configured as alarms. For each output it is
possible to set:
c Any of the parameters measured by the CVM 96
d MAXIMUM value
e MINIMUM value
f Delay for the conditions
These screens are successively displayed by the CVM 96 once the parameter
has been selected ( for the SETUP of each option proceed as in the Section a.-):
b.1.- Programming the maximum value to be controlled:
OUT 1 RELAY 1
AL hI
0.000
( Maximum value
The key "max" will increase the value of the blinking digit (0,1...9, sign -- ). Use
the key "min" to pass to the following digit.
To Next Page
