----- Supply network analyzer CVM 96 Ethernet -------- ----- Page No. 27
b.2.- Programming the minimum value to be controlled:
OUT 1 RELAY 1
AL LO
0.000
( Minimum value
b.3.- Programming the delay:
OUT 1 RELAY 1
SEC Delay in seconds
0.000
( maximum 9999 s
THD parameters can also be selected as alarm conditions.
- Press " " to pass to the next option: the SETUP for the second relay is then
shown:
OUT 2 RELAY 2
CODE
00
( Parameter No. (1)
Proceed as before. Pressing again " " the SETUP option exited.
---------------------------------------------------------------------------
