----- Supply network analyzer CVM 96 Ethernet -------- ----- Page No. 39
MODBUS REGISTERS
HEXA-DECIMAL (longs)
PARAMETER
Units
L1 L2 L3
Fundamental mA 1F4-1F5 212-213 230-231
Harmonic 2 % 1F6-1F7 214-215 232-233
Harmonic 3 % 1F8-1F9 216-217 234-235
Harmonic 4 % 1FA-1FB 218-219 236-237
Harmonic 5 % 1FC-1FD 21A-21B 238-239
Harmonic 6 % 1FE-1FF 21C-21D 23A-23B
Harmonic 7 % 200-201 21E-21F 23C-23D
Harmonic 8 % 202-203 220-221 23E-23F
Harmonic 9 % 204-205 222-223 240-241
Harmonic 10 % 206-207 224-225 242-243
Harmonic 11 % 208-209 226-227 244-245
Harmonic 12 % 20A-20B 228-229 246-247
Harmonic 13 % 20C-20D 22A-22B 248-249
Harmonic 14 % 20E-20F 22C-22D 24A-24B
Harmonic 15 % 210-211 22E-22F 24C-24D
NOTE: The maximum number of parameters (1 parameter = 1 word of 32 bits) that can be
read in one transmission is 20.
