Circutor Raption Series Service Manual

Service Manual 105
Raption
MODELS SPECIFICATIONS
(Continuation) Raption 50 HV / Raption 50 EVO - 400V Models
MODELS
CCS1 T2S32
CCS2 T2S32
CCS1-CHA T1C32
CCS2-CHA T2C32
CCS1-CHA T2S32
CCS2-CHA T2S32
Maximum AC input
current
108 A 108 A 108 A
Required power supply
capacity
75 kVA 75 kVA 75 kVA
Maximum output
power
DC: 50 kW(@400Vdc)
AC: 22 kW
CCS1-CHA T1C32
DC: 50 kW (@400Vdc)
AC: 22 kW
DC: 50 kW(@400Vdc)
AC: 7.4 kW
CCS2-CHA T2C32
DC: 50 kW(@400Vdc)
AC: 22 kW
Output voltage range
DC: 150 - 920 Vdc
AC: 400 V~
CCS1-CHA T1C32
DC: 150 - 920 Vdc
AC: 400 V~
DC: 150 - 920 Vdc
AC: 230 V~
CCS2-CHA T2C32
DC: 150 - 920 Vdc
AC: 400 V~
Maximum output
current
DC: 125 A
AC: 32 A
DC: 125 A
AC: 32 A
DC: 125 A
AC: 32 A
Number of connectors 3 3 3
Connector type
CCS1 T2S32 CCS1-CHA T1C32 CCS1-CHA T2S32
C
M M
B
C
CCS2 T2S32 CCS2-CHA T2C32 CCS2-CHA T2S32
K K K
C
M M
C C
