Circutor Raption Series Service Manual

Raption
106 Service Manual
MODELS SPECIFICATIONS
Raption 50 HV / Raption 50 EVO - 480V Models
Raption 50 HV Power output DC of 50 kW (non upgradable).
Raption 50 EVO Power output DC of 50 kW (upgradable up to 100 kW).
MODELS CCS1 CCS1 CHA CCS1 T1C32
Maximum AC input
current
63 A 63 A
63 A (@480V 3F)
35 A (@208-240V F-N)
Required power supply
capacity
53 kVA 53 kVA 75 kVA
Maximum output
power
DC: 50 kW (@400Vdc) DC: 50 kW (@400Vdc)
DC: 50 kW(@400Vdc)
AC: 7.4 kW
Output voltage range DC: 50 - 500 Vdc DC: 50 - 500 Vdc
DC: 150 - 920 Vdc
AC: 208 - 240 V~
Maximum output
current
DC: 125 A DC: 125 A
DC: 125 A
AC: 32 A
Number of connectors 1 2 2
Connector type
M
B
MODELOS CCS1 T2S32 CCS1-CHA T1C32 CCS1-CHA T2S32
Maximum AC input
current
63 A (@480V 3F)
35 A (@208-240V F-N)
63 A (@480V 3F)
35 A (@208-240V F-N)
63 A (@480V 3F)
35 A (@208-240V F-N)
Required power supply
capacity
75 kVA 75 kVA 75 kVA
Maximum output
power
DC: 50 kW(@400Vdc)
AC: 7.4 kW
DC: 50 kW(@400Vdc)
AC: 7.4 kW
DC: 50 kW(@400Vdc)
AC: 7.4 kW
Output voltage range
DC: 150 - 920 Vdc
AC: 208 - 240 V~
DC: 150 - 920 Vdc
AC: 208 - 240 V~
DC: 150 - 920 Vdc
AC: 208 - 240 V~
Maximum output
current
DC: 125 A
AC: 32 A
DC: 125 A
AC: 32 A
DC: 125 A
AC: 32 A
Number of connectors 2 3 3
Connector type
C
M M
B
C
